3 tons Diesel Powered Forklift Manufacturer

Forklifts, also known as lift trucks or forklift trucks, are essential material handling equipment widely used in various industries, including warehousing, logistics, manufacturing, and construction. They are designed to lift, transport, and stack heavy loads efficiently, enhancing workplace productivity and safety

Inquiry now

product introduction

Generals	1	Model 型号			UNIT	DH30Z(液力)	DH30(机械)	DH35Z(液力)	DH35(机械)
	2	Power type 动力形式				Diesel/ Gasoline/LPG 柴油/汽油/液化气
	3	Rated capacity 额定载荷			kg	3000	3000	3500	3500
	4	Load center 载荷中心距			mm	500	500	500	500
Dimensions	5	Lift height 起升高度			mm	3000	3000	3000	3000
	6	Free lift height 自由起升高度			mm	130	130	130	130
	7	Fork size(LWT)货叉尺寸			mm	1070×125×45	1070×125×45	1070×125×45	1070×125×45
	8	Fork outside spread(Min./Max.)货叉间距（外侧）			mm	300/1200	300/1200	300/1200	300/1200
	9	Mast tilt range(F/R)门架倾角（前/后）			deg	6/12	6/12	6/12	6/12
	10	Front overhang 前悬距			mm	490	490	490	490
	11	Overall dimensions	Length to face of fork 总长	Without of fork 不带货叉	mm	2750	2750	2800	2800
	12			With fork 带货叉	mm	3820	3820	3870	3870
	13			Wheel width 车轮宽	mm	1225	1225	1225	1225
	14		Mast lowered height 门架不起升高度		mm	2095	2095	2095	2095
	15		Mast extended height 门架起升高度		mm	4180	4180	4180	4180
	16		Overhead guard height 安全架高度		mm	2130	2130	2130	2130
	17	Turning radius 最小转弯半径			mm	2460	2460	2510	2510
	18	Min. right angle aisle width 最小直角通道宽度			mm	2105	2105	2200	2200
Performance	19	Travel speed (unload/full load) 行驶速度（空载/满载）			km/h	20/18.5	20/18.5	20/18.5	20/18.5
	20	Lift speed (unload/ full load) 起升速度（空载/满载）			mm/s	480	480	480	480
	21	Self weight自重			kg	4250	4250	4500	4500
	22	Max. gradeability 最大爬坡度			%	20	20	20	20
Wheel & Tires Drive units	23	Tires 轮胎		Front 前轮		28×9-15-12PR	28×9-15-12PR	28×9-15-12PR	28×9-15-12PR
	24	Tires 轮胎		Rear 后轮		6.50-10-10PR	6.50-10-10PR	6.50-10-10PR	6.50-10-10PR
	25	Tread 轮距		Front 前轮	mm	1000	1000	1000	1000
	26	Tread 轮距		Rear 后轮	mm	970	970	970	970
	27	Wheelbase 轴距			mm	1700	1700	1700	1700
	28	Min. ground clearance 最小离地间隙（unload/ full load）（空载/满载）		Mast 门架	mm	152/132	152/132	152/132	152/132
	29	Min. ground clearance 最小离地间隙（unload/ full load）（空载/满载）		Frame 车架	mm	158/138	158/138	158/138	158/138
	30	Battery 蓄电池			v/ah	12/90	12/90	12/90	12/90
	31	Engine 发动机		Model 型号		4D27G31	4D27G31	4D27G31	4D27G31
	32			Rated output 额定功率	kw/r.p.m	36.8/2500	36.8/2500	36.8/2500	36.8/2500
	33			Rated torque 额定扭矩	n.m/r.p.m	156/1700-1900	156/1700-1900	156/1700-1900	156/1700-1900
	34			Displacement 排量	cc	2670	2670	2670	2670
	35			No. of cylinder 缸数		4	4	4	4
	36			Borestroke 缸径×行程	mm	90×105	90×105	90×105	90×105
	37	Transmission 双变		Model 型号		Hydraulic	Hydraulic	Hydraulic	Hydraulic
	38	Transmission 双变		Shift (FWD/RVS) 档位（前/后）		1/1	2/2	1/1	2/2
	39	Operating pressure 工作压力			mpa	17.5	17.5	17.5	17.5
