Product Description:   The boom cylinder (new type) is a reciprocating actuator in the hydraulic system. A double acting single rod piston hydraulic cylinder with simple structure, reliable operation, convenient disassembly, easy maintenance and other characteristics. Performance characteristics: 1. Cylinder diameter 160 2. Rod diameter 80 3. Trip 930 4. The installation distance is 380 5. Working pressure is 16MPa 6. Cylinder body hinge shaft installation, rod end single earring. Adaptation: XGMA XG951-Ⅲ loader Note: The specific color is based on real objects

Product Description:   Steering cylinder is a reciprocating actuator in hydraulic system. A double acting single rod piston hydraulic cylinder with simple structure, reliable operation, convenient disassembly, easy maintenance and other characteristics. Performance characteristics: 1. Cylinder diameter 90 2. Rod diameter 45 3. Trip 340 4. The installation distance is 583 5. Working pressure 14MPa 6. Cylinder block single earrings, rod end single earrings. Adaptation: XGMA XG951XG951ⅡXG951-Ⅲ loader

  Product Description: Wiper motor (DC permanent magnet motor) by the motor and worm gear mechanical part of a whole. With deceleration and torque increase, driving wiper handle to scrape the rain on the windshield, ensure clear vision, driving operation safety of the main device. Performance parameter Rated voltage: 24V Power: 30W Adaptation :XGMA XG951II series loaders and corresponding construction machinery of this specification model

Product Description:   Gear oil pump has the characteristics of simple and compact structure, good technology, strong self-suction, insensitive to oil pollution, impact load resistance, easy maintenance, reliable operation and so on. Loader steering hydraulic system is the main device. Technical parameters: Nominal displacement: 80ml/r Rated pressure: 20MPa Shaft extension form: flat key Adaptor: XGMA XG951Ⅱ Loader (steering hydraulic system)

Product Description:   Gear oil pump has the characteristics of simple and compact structure, good technology, strong self-suction, insensitive to oil pollution, impact load resistance, easy maintenance, reliable operation and so on. It is the main device of loader hydraulic system. Technical parameters: Nominal displacement: 100ml/r Rated pressure: 20MPa Shaft extension form: (rectangular six-spline) 6-30*26*8 Adaptation: LONKING LG5 series loader (working hydraulic system)

Product Description:   Oil return hydraulic filter element is to filter and prevent impurities in hydraulic components and pipelines and other hydraulic oil again, to prevent high filtration accuracy, large flow rate and long service life inside the hydraulic tank. Adaptation: Xiagong 951-3 953-3

Product Description:   The air filter is installed on the top or side of the oil tank, and its main function is to filter the impurities in the oil products, and purify and filter the gas in and out of the oil tank. Adaptation: Longgong building workers universal

  Product Description: The variable speed control valve has the functions of compact structure, good technology and adaptability to bad working conditions. It is an important device to realize the hydraulic pressure and gear control of the loader transmission. Performance parameter Working pressure :1.1-1.5MPa Flow rate :80L/min Adaptation :XGMA XG951 XG953 longking LG850855856 Loader transmission hydraulic system

Product Description:   ZL50Ⅱ grade driven sheet has high strength, certain toughness and plasticity, tensile yield strength, good thermal conductivity, wear resistance and long service life. Technical parameters: with diameter of 280× 250× 200 Adaptation: 1, LiugongZL50CZL50CNCLG855CLG855NCLG856 loader 2, XGMA XG932Ⅱ932Ⅲ932H951951Ⅱ951Ⅲ951H953953Ⅲ953H955Ⅲ955H loader 3, LongkingLG850853855856 series loader 4. TOTAXZ50 series loader 5, SDLG936 936 LG952 LG952H LG953 LG953N LG956 LG956L loader 6, supporting the specification of the type of planetary transmission

ZL50 inverted and I gear driving plates have high mechanical strength, high thermal conductivity, high thermal stability, good friction coefficient, and excellent friction and wear (wear resistance) and ablative resistance, long service life. Technical parameters: Diameter of 305× 235.45 Adaptation: 1, LiugongZL50CZL50CNCLG855CLG855NCLG856 loader 2, XGMA XG932Ⅱ932Ⅲ932H951951Ⅱ951Ⅲ951H953953Ⅲ953H955Ⅲ955H loader 3, LongkingLG850853855856 series loader 4. TOTAXZ50 series loader 5, SDLG936 936 LG952 LG952H LG953 LG953N LG956 LG956L loader 6, supporting the specification of the type of planetary transmission

Product Introduction: The variable speed pump (walking pump) has the function of simple structure, compact, easy installation, controlling the pressure of the transmission hydraulic system and the working pressure of the torque converter. It is a special hydraulic pump in the planetary transmission hydraulic system of construction machinery. Performance Characteristics Displacement: 70ml/r Working pressure: 1.4-1.6MPa Speed :1800-2200r/min Adaptation: 50 loader of XGMA Longking industrial installation and supporting (planetary gearbox)

Product Description:   The loader tire is a low pressure wide base tire, which has the characteristics of good adhesion, skid resistance and wear resistance. It is an important part of the loader walking system. Technical parameter Specifications and models: 23.5-25-24 Adaptation: 5 ton loader
